Rigging Hardware
Heavy-Duty Off-Road Shackle Hitch Receiver (Square Receiver + Bow Shackle Combo)
Solid steel 2" hitch receiver with a customizable red G-209 bow shackle, rubber isolator and screw pin—converts a rigid hitch square into a multi-directional recovery anchor for off-road, towing and winch work.
Request a Quote1. Product Overview
This is a heavy-duty automotive shackle hitch receiver assembly (shackle hitch converter) designed for off-road vehicles, pickups and rescue trucks. It combines a black solid-steel square hitch bar machined for a standard 2" receiver with a front red forged bow shackle (G-209 type) configured to customer WLL and size requirements. By converting the rigid hitch square into a swinging bow-shackle anchor, it greatly improves safety and convenience for off-road recovery, heavy towing, roadside rescue and cargo securement.
2. Key Features & Design Highlights
- Solid steel hitch bar: Machined from solid carbon or alloy steel—not hollow tube or cast iron—for high impact and shear resistance under hard pulls. Square section with a standard hitch pin hole; can be inserted horizontally or vertically as needed.
- Matte black powder coat: Heavy industrial coating resists stone chips, mud abrasion and long-term corrosion.
- Custom red bow shackle: Forged alloy steel G-209 bow shackle available in customer-specified WLL (e.g. 2T, 3.25T, 4.75T) and nominal size, heat treated and finished in high-visibility red paint contrasting with the black bar.
- Rubber shackle isolator: Thick ribbed rubber sleeve on the bow crown plus pin washers reduce rattle and metal-on-metal contact during driving, and protect soft tow straps and winch rope from sharp edges.
- Screw-pin quick connect: Hardened blackened or galvanized threaded pin with flat head and hole for hand or tool tightening—fast hook-up to tow straps, rings, chain or winch hooks in the field.
3. Primary Applications
- Off-road recovery anchor for SUVs and pickups (Jeep, Land Cruiser, Raptor class)—mud, sand and snow extractions with a safe swinging pull point.
- Roadside towing and trailer connections for small boat trailers, RVs and ATV carriers within rated capacity.
- Winch snatch blocks and directional changes during complex recoveries.
- Cross-securement terminals on utility, survey and military transport vehicles.
4. Specifications
| Product Type | Shackle hitch receiver (square receiver + bow shackle combo) |
|---|---|
| Receiver Material | Solid steel, precision machined |
| Receiver Finish | Matte black industrial powder coat |
| Receiver Fit | Standard 2" × 2" hitch receiver (custom sizes available) |
| Bow Shackle | Forged alloy steel G-209 type (WLL and size per customer order) |
| Shackle Finish | High-visibility industrial red paint |
| Isolator | Heavy-duty rubber shackle sleeve + pin washers |
| Pin Type | Integral threaded screw pin (quick connect) |
Safety Guidelines
- Fully tighten the screw pin before loading—never pull with the pin only partially threaded or the threads can strip and the shackle can release.
- Match shackle WLL to vehicle towing capacity and recovery conditions—do not exceed the rated assembly.
- Do not weld, cut or heat the receiver or shackle—machining and heat treatment must not be altered.
